Cross App Access

Cross App Access and this profile get read as competitors. They are not. They answer different questions about the same request, and a request over an organization's resources needs both answers.

Cross App Access (ID-JAG)   which employee is this agent acting for,
                            and did an administrator approve this
                            application reaching that resource at all

this profile                and therefore what may it do to the
                            resource, on whose terms, for how long,
                            and at what depth of delegation

Northwind cannot know what Alice's terms say. Alice's authority cannot know whether Northwind's administrator approved this application at all. Each party answers the question it is actually in a position to answer.

What an ID-JAG is

An Identity Assertion JWT Authorization Grant — draft-ietf-oauth-identity-assertion-authz-grant, also called XAA. A client exchanges the employee's ID token at the identity provider for a short-lived assertion audienced at one authorization server and naming one resource. It is not an access token and it carries no entitlement.

That last property is what makes it compose. An assertion that carried entitlement would have to be honoured or overridden; one that carries only identity and approved reach can be asked for by whoever needs to know, and answered without settling anything else.

The wire

The assertion arrives as a claim against an open permission ticket — the slot UMA has always had for "prove something about yourself before I dictate terms". The negotiation gains one beat, and each beat asks exactly one party's question.

agent → resource server            tools/call
     ← 401 WWW-Authenticate: UMA   as_uri, ticket

agent → authorization server       ticket
     ← 403 need_info               required_claims: [id-jag]
                                   + which provider, what audience,
                                     what resource, which scope

agent → identity provider          token exchange
     ← ID-JAG

agent → authorization server       ticket + claim_token=<ID-JAG>
     ← 403 need_info               required_claims: [agreement]
                                   + terms_template

agent → authorization server       ticket + claim_token=<signed agreement>
     ← 200                         RPT

Identity comes first because the answer decides what follows: which tier applies, and what her terms may say, both depend on which member the agent acts for.

It is the resource side that starts it

Cross App Access is usually drawn outwards from the identity provider, which makes it sound like something an enterprise pushes at an application. Nothing here is pushed.

The agent begins knowing nothing about Northwind. It calls a tool, is refused, and is told which provider to go to, what to name as the audience and the resource, and which scope to ask for — all of it inside the required_claims object. Only then does it go and get one.

This is the same shape as every other beat in this profile: the resource side states what it needs, and the requesting side decides whether to satisfy it. An agent carrying no enterprise credentials is refused at that point in plain terms rather than left guessing.

Three ceilings, one per party

the provider's connection scope     what an administrator approved

∩ the charter's grants what the organization allows the role ∩ her terms what she is willing to offer = what the grant actually carries

None of the three can widen another, and each is set by a party with standing to set it. A scope no administrator approved is refused at the identity provider. An agent somebody else operates is refused by the charter's first-party-only role despite a perfectly good assertion — whose agent it is remains the member's own declaration, not something an employer asserts. And her terms narrow whatever is left.

Where the enterprise half stops

The identity provider is consulted only where the organization actually reaches the resource. That test already subtracts anything the member holds jointly with somebody else, and it never matched her own accounts to begin with.

So her personal vault is never governed by this. No assertion is asked for over it, and none would help — there is no beat in that negotiation where one would be accepted. The boundary is the same one the organization layer already draws; Cross App Access does not move it.

Who masters what

Three parties, and each masters exactly one thing:

That division answers the awkward case: an employee's agent turns up with a perfectly good assertion, at a resource belonging to an organization she has not joined. The request is refused, and the assertion does not enrol her.

It cannot be allowed to. Joining is a bargain — the charter narrows her terms, but it also gives the organization powers over her agents, break-glass among them. Those are acquired by agreeing to a document, not by being on a payroll. An employer able to enrol somebody by asserting they work there could put a stranger's authority under a charter they never read, which is the arrangement the organization layer exists to make impossible.

So the refusal is flat and carries no challenge — there is nothing to negotiate about a resource nobody has shared. What it does carry is the organization's name and how membership is come by, which is the difference between a dead end and something the person can act on. None of that is privileged; the organization publishes it.

Enrolling because the directory says so

Where a charter names a provider, an employee enrols as a member on the strength of her employer's own directory rather than a shared code. The charter is what makes that legitimate: she reads that the organization federates identity to a named provider before she agrees to anything, so an organization cannot start accepting somebody else's word about who its people are without republishing the bargain.

Omit identity_provider from the charter and none of this exists — members enrol with a code exactly as before, and no assertion is asked for or accepted.

Running it

make xaa-check walks the whole arrangement: the federated charter, enrolment by assertion, the two-beat negotiation, all three ceilings biting separately, and the boundaries — one authority, one person, one use, and nothing outside the organization's own resources.

Two identity providers, and they are different companies

Conflating them is the easiest mistake here. Meridian runs one, which authenticates people into Meridian's own surfaces — the member's portal, and the console the administrator signs into. Northwind runs another, which is a customer's own infrastructure: its employee directory, its administrator, and the issuer a charter federates to.

They are separate deployments in the lab because they are separate companies. Meridian's word about who Northwind employs is worth nothing, and that is asserted rather than assumed: a token from Meridian's provider is refused both at Northwind's exchange endpoint and as an employee assertion at enrolment.

Northwind's is Keycloak only because the lab needs a real OpenID provider to stand in for an enterprise tenant, and the exchange endpoint sits beside it because Keycloak can receive an ID-JAG but cannot yet issue one. A tenant with Cross App Access does both halves in one place, and pointing the charter at one is the only change required — keys are found by discovery rather than a lab convention, permitted algorithms come from the key's type rather than the token's header, and the claim naming the person is not assumed.

See deviation 17 for why the assertion is carried as a claim rather than as a jwt-bearer grant.
